GSK 928TD-L Lathe CNC Controller from GSK CNC Equipment Co., Ltd.
Can replace GSK 928TEII, same dimension, color screen, adding USB function.

Download GSK 928TD-L User Manual here
GSK928TD User Manual English Version




GSK 928TD-L CNC lathe system



The new GSK928TD-L lathe numerical control system adopts high-performance dual-core CPU and ultra-large scale PROGRAMMABLE gate array integrated circuit chip FPGA to constitute the control core, and realizes μ -level precision motion control.Can support absolute servo motor and AC servo drive unit, through programming can complete the outer circle, end face, grooving, taper, arc, thread and other processing.



(Note: detailed specifications, models, prices and other inquiries, please contact customer service to negotiate, do not directly place an order, otherwise not shipped)

I/O (input detection / output control)

●Controllable spindle, tool holder, chuck, tailstock, cooling, pressure detection, external start pause, feed holding knob and other devices (fixed pin)

●Controllable tricolor lamp, hand pulse, protective door, lubrication, headstock lubrication, shift unit, feeding unit and other devices (pins arranged by the machine tool factory)



Simple operation

●Flexible and diverse help functions

●Full screen editing, error checking of part program in advance, simulation and drawing of motion track;
●Introduction to editing mode system instructions
●All kinds of operation are simple, safe and easy to use



Multilingual interface conversion

●Special display interface can be designed by ourselves



Special display interface can be designed by ourselves

●The display surface can be designed to prompt the operator how to operate



High speed smooth interpolation of short line

●Adopt forward-looking control to realize high-speed connection and transition;

●Smooth machining of ellipse and parabola with short straight line without stun mark



Pitch error inflection point input Fine density compensation

●Just input several groups of inflection point data on the curve to automatically carry out fine and smooth compensation!
