GSK 980TDi CNC lathe system
GSK 980TDi is a new member of GSK 980TD product family. It is created by the original team members who have successfully developed GSK 980TD, GSK 980TDa, GSK 980TDb, GSK 980TDc and other products.Is following GSK 980TDc after Guangzhou CNC for universal CNC lathe and turning center market of the latest work.
Based on GSK-Link industrial fieldbus, GSK 980TDi is equipped with bus-type servo drive unit and multi-turn 23-bit absolute encoder servo motor, realizing 1nm position accuracy, servo parameter online configuration and mechanical zero without block.At the same time, invited experts in the field of well-known industrial design to undertake a brand new design of the exterior structure, which makes people find everything new and fresh.In addition, the project team has done a lot of research work in efficiency improvement, intelligent application, humanized operation, user secondary development and other aspects.
Technical characteristics
○Based on GSK-Link industrial fieldbus;The minimum moving unit is 0.1um, and the maximum moving speed is 100m/min;Support turning and milling compound processing;
○Support torque control;
○Support online configuration of servo parameters and real-time monitoring of servo status;
○Support the secondary development of the display interface (user-defined);
○Support mechanical zero return without stop;
○Standard bus-type servo drive unit and multi-turn 25-bit absolute encoder.
Support online servo debugging
GSK980TDi can remotely collect CNC theoretical data and machine tool data in real time through the PC debugging software. Through the oscilloscope function, the collected data can analyze its speed characteristics, real-time trajectory, roundness, and tapping performance from various aspects such as position, speed, and current. . Through intuitive graphs, online adjustment of servo parameters can quickly realize the analysis and debugging of servo characteristics, which greatly improves the overall performance of the machine tool and simplifies the time spent on machine tool debugging.
High-speed and high-precision control
Based on the GSK-Link industrial field bus, the servo motor equipped with GR-L series servo device and 25-bit and above high-resolution absolute encoder can realize nano-level interpolation, so that the output accuracy of the system and the feedback accuracy of the servo motor encoder can be realized. Matching, give full play to the performance of high-resolution encoder servo motor, and then achieve high-speed, high-precision processing effect.
Support turning and milling combined processing
The system has 5 feed axes and 2 analog spindles. When it is adapted to a servo spindle, it can realize spindle orientation, rigid tapping, cylindrical interpolation, and polar coordinate interpolation to meet the requirements of turning and milling combined processing.
Thread repair function
Thread repair function, regardless of whether the machine tool is equipped with a servo spindle or an analog spindle, it can repair damaged threads (large petroleum pipelines or screw rods).
Technical parameter |
|||
Item |
Specification |
||
Number of control axes |
Max number of control axes: 5 axes |
||
Max number of linkage axes: 5 axes (linear interpolation), 2 axes (circular interpolation) |
|||
Number of PLC control axes: 5 axes |
|||
|
Workpiece coordinate system (G50), local coordinate system, workpiece coordinate system 1~6 (G54~G59) |
||
Coordinate plane selection |
|||
Position command range: ±99999999 x min input unit |
|||
Absolute/incremental programming, diameter/radius programming, inch/metric conversion, linear axis/rotary axis |
|||
G Function |
Contains 69 G commands, including rapid positioning, linear interpolation, circular interpolation, cylindrical interpolation, thread cutting, polar coordinate interpolation, polygon turning, rigid tapping, pause, drilling, tool compensation, macro program calling, Jump, loop, tilt axis control, thread repair, etc. |
||
Feed Function |
Rapid speed: 0mm/min ~ 100000mm/min |
||
Rapid magnification: F0, 25%, 50%, 100% a total of four levels of real-time adjustment |
|||
Cutting feed speed: 0mm/min ~ 15000mm/min |
|||
Feed magnification: 0~150% a total of sixteen levels of real-time adjustment |
|||
Rapid/cutting feed acceleration and deceleration: linear type and S type. The starting speed, ending speed and acceleration and deceleration time of acceleration and deceleration are set by parameters. |
|||
BUS Function |
Servo motor for multi-turn absolute position encoder |
||
Automatic restoration of absolute coordinate system of machine tool after power failure |
|||
Machine Tool No Stop Block Mechanical Return Zero |
|||
Servo parameters can modified on controller |
|||
On-line diagnosis of servo state |
|||
Operation logs, Run logs, Processing logs |
|||
Remote monitoring, GSK LINK diagnostic function |
|||
Thread Cutting |
Thread type: equal pitch straight thread taper thread / end thread / arc thread, variable pitch straight thread / taper thread / end thread and other tip width variable lead thread |
||
Thread head: 1-99 |
|||
Thread pitch: 0.01mm ~ 1000mm (metric thread) or 0.06tooth/inch ~ 2540 tooth/inch (British thread) |
|||
Thread cutting acceleration and deceleration: linear, exponential, S type can be set |
|||
Thread backtail: backlength, angle and speed characteristics can be set |
|||
Spindle Function |
Spindle speed: It can be given by the S code or the PLC signal, with a speed range of 0 ~ 9999rpm |
||
Spindle override: 50%~120%, a total of eight levels, real-time adjustment |
|||
2 channels 0V~10V analog voltage output, support flexible tapping/rigid tapping |
|||
2 channels of spindle encoder feedback, the number of spindle encoder lines can be set |
|||
Tool function |
Tool length compensation (tool offset): 32 groups |
||
Tool wear compensation: 32 groups |
|||
Tool life management: 32 groups (8 tools/group) |
|||
Tool nose radius compensation (C type) |
|||
Tool setting methods: fixed-point tool setting, trial cutting tool setting, reference point return to tool setting, automatic tool setting, coordinate recording function |
|||
Tool offset execution mode: modify coordinate mode, tool movement mode |
|||
M function |
Special M codes (M 00, M 01, M 02, M 30, M 98, M 99), other M codes are defined by PLC |
||
PLC function |
Two-level PLC program, up to 5000 steps, the first-level program refresh cycle is 8ms |
||
13 basic instructions, 44 functional instructions |
|||
PLC program online display and real-time monitoring; support PLC warning and PLC alarm |
|||
Support multiple PLC programs, the currently running PLC program can be selected |
|||
Basic I/O: 48 input/38 output |
|||
Scalable serial I/O unit (optional): IOR-04T: 48 points input, 32 points output, no analog voltage output |
|||
Program storage and editing |
Program capacity: 64M, 10,000 programs (including subprograms and macro programs) |
||
Editing mode: full screen editing |
|||
Editing function: program/program segment/word retrieval, modification, deletion, copy, paste |
|||
MDI allows input and operation of 10 blocks |
|||
Support macro program/subprogram call, allowing 4-fold subprogram nesting |
|||
Calculator |
|||
Auxiliary programming |
|||
Program check function |
Track preview, graphics simulation, dry run, machine lock, auxiliary function lock, single-segment run, stored stroke detection |
||
Simplified programming functions |
Canned cycle, multiple canned cycle, rigid tapping, direct input of drawing size, automatic chamfering, sentence-style macro programming |
||
Compensation function |
Backlash compensation: 0mm~2mm (or 0inch~0.2inch), the backlash compensation method and frequency are set by parameters |
||
Memory type pitch error compensation: 1024 compensation points in total, parameter setting of compensation points for each axis |
|||
HMI |
8.4 inches / 10.4 inches LCD |
||
Support Chinese, English and other languages display |
|||
The processing track display, the processing track can be zoomed in and out in real time, and the font of the program content can be zoomed in or out |
|||
Position, program, tool compensation, alarm, parameter, setting, graphics, diagnosis, ladder diagram, help |
|||
Operation Management |
Operation mode: edit, automatic, input, mechanical zero return, MPG/single step, manual, program zero return, MPG trial cutack |
||
6-level operation authority management |
|||
A max of 32 time-limited shutdowns can be set |
|||
Program switch, parameter switch |
|||
MPG interruption, teaching |
|||
Machine function debugging, |
|||
Regular maintenance function |
|||
Communication function |
USB: U disk file operation, U disk file direct processing, support PLC program, system software U disk upgrade |
||
RS 232: two-way transmission of part programs, parameters and other files, screw compensation parameters import and export, support PLC program update |
|||
LAN: remote file transfer |
|||
security function |
Emergency stop, hardware travel limit, software travel check, data backup and recovery |
||
Electrical Interface |
48/38 point digital input and output interface, 2 encoder interfaces, 2 handwheel interfaces, 2 spindle analog interfaces, RJ 45 network ports, GSK-LINK network ports |
||
Size |
8.4 inch screen |
GSK980TDi(W×H×D) |
420×260x150mm |
GSK980TDi-V(W×H×D) |
292×422×150mm |
||
GSK980TDi-H(W×H×D) |
400x400×150mm |
||
10.4 inch screen |
GSK980TDi(W×H×D) |
480×405×150mm |
|
GSK980TDi-V(W×H×D) |
292×705x150mm |
●GSK Link Industrial Ethernet bus control
●5 axis 5 linkage (straight line), minimum control accuracy 0.1 μ m. Maximum moving speed 100M / min
●Online cam function, read DXF file and generate machining program
●It supports on-line servo parameter configuration,real-time servo status monitoring and mechanical zero return without stop
●It has the functions of programming wizard and automatic programming of plane milling
●It supports I / O unit expansion and can be adapted to disc magazine, hat magazine and turret magazine
●Support secondary development of display interface (user-defined page)
●Support rigid tapping, cylindrical interpolation and indexing table control
●Support high-speed small segment program die machining
●Peripheral axis control is supported. There are 5 peripheral axis control groups in total
●Support one click breakpoint data recovery
●Support rigid tapping and roundness waveform analysis
●With torque protection function
